Milton CAT 385C L - Manual (Page 21)

21 385C L Hydraulic Excavator specifications
Reach Boom Lift Capacities
6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft 12.0 m/40.0 ft 13.5 m/45.0 ft 15.0 m/50.0 ft
m
ft
13.5 m kg *5200 *5200 13.10
45.0 ft lb *11,600 *11,600 42.30
12.0 m kg *8040 *8040 *4920 *4920 14.31
40.0 ft lb *15,600 *15,600 *10,900 *10,900 46.51
10.5 m kg *9730 *9730 *4780 *4780 15.24
35.0 ft lb *20,650 *20,650 *10,550 *10,550 49.70
9.0 m kg *10 250 *10 250 *8830 7780 *4740 *4740 15.94
30.0 ft lb *22,350 22,100 *17,750 16,450 *10,450 *10,450 52.10
7.5 m kg *11 760 *11 760 *10 710 10 060 *9900 7650 *4780 *4780 16.44
25.0 ft lb *25,500 *25,500 *23,250 21,500 *21,600 16,250 *10,500 *10,500 53.82
6.0 m kg *14 560 *14 560 *12 670 12 600 *11 300 9650 *10 260 7410 *7680 5600 *4890 4420 16.76
20.0 ft lb *31,450 *31,450 *27,400 27,050 *24,500 20,650 *22,300 15,750 *10,750 9800 54.95
4.5 m kg *25 610 *25 610 *19 640 *19 640 *16 050 15 600 *13 660 11 870 *11 950 9170 *10 670 7100 *9250 5440 *5080 4140 16.93
15.0 ft lb *54,950 *54,950 *42,300 *42,300 *34,650 33,600 *29,550 25,500 *25,900 19,600 *23,150 15,100 *17,750 11,500 *11,200 9150 55.53
3.0 m kg *25 180 *25 180 *21 800 19 300 *17 460 14 460 *14 610 11 120 *12 590 8670 *11 070 6780 9210 5250 *5360 3980 16.94
10.0 ft lb *62,560 58,250 *47,000 42,650 *37,700 31,150 *31,550 23,900 *27,250 18,550 *23,950 14,350 19,650 11,100 *11,800 8800 55.58
1.5 m kg *16 020 *16 020 *23 390 17 790 *18 600 13 460 *15 400 10 440 *13 120 8200 11 030 6460 9010 5060 *5730 3950 16.80
5.0 ft lb *38,400 *38,400 *50,500 38,350 *40,200 28,950 *33,300 22,400 *28,400 17,550 23,650 13,750 19,250 10,700 *12,600 8700 55.11
Ground kg *15 580 *15 580 *24 240 16 740 *19 330 12 680 *15 940 9870 13 190 7800 10 750 6190 8840 4900 *6220 4040 16.49
Line lb *36,500 *36,500 *52,400 36,050 *41,800 27,250 *34,450 21,200 28,300 16,700 23,000 13,200 18,900 10,400 *13,700 8900 54.11
–1.5 m kg *18 110 *18 110 *24 360 16 120 *19 580 12 140 16 010 9460 12 870 7500 10 530 5990 *6870 4270 16.02
–5.0 ft lb *41,900 *41,900 *52,700 34,650 *42,350 26,100 34,400 20,300 27,600 16,050 22,600 12,800 *15,200 9450 52.53
–3.0 m kg *22 380 *22 380 *23 800 15 830 *19 310 11 850 15 740 9210 12 670 7310 10 420 5890 *7760 4690 15.36
–10.0 ft lb *51,500 48,850 *51,500 34,050 *41,700 25,450 33,800 19,750 27,200 15,650 22,350 12,600 *17,150 10,400 50.33
–4.5 m kg *28 020 22 920 *22 580 15 820 *18 470 11 760 *15 270 9130 12 630 7270 *10 200 5910 *8160 5370 14.50
–15.0 ft lb *60,650 49,200 *48,800 34,000 *39,850 25,300 *32,850 19,600 *27,100 15,600 *21,450 12,700 *17,950 11,900 47.40
–6.0 m kg *25 250 23 350 *20 620 16 030 *16 960 11 880 *13 940 9220 *11 230 7390 *7620 6460 13.37
–20.0 ft lb *54,500 50,150 *44,400 34,450 *36,400 25,550 *29,800 19,850 *23,700 15,900 *16,700 14,450 43.59
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤ ➤ ➤
➤
➤
➤
➤ ➤ ➤ ➤ ➤
➤
➤
➤
BOOM – 10 m (32'10")
STICK – 5500 mm (18'1") BUCKET – 1374 mm (54") GP with HD long tips
SHOES – 900 mm (36") double grouser UNDERCARRIAGE – Long
HEAVY LIFT – On
Load at
Maximum Reach Load Point
Height Load Radius
Over Front Load Radius
Over Side
* Indicates that the load is limited by hydraulic capacity rather than tipping capacity. Lift capacity ratings are based on SAE standard J1097.
Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity.
* Indicates that the load is limited by hydraulic capacity rather than tipping capacity. Lift capacity ratings are based on SAE standard J1097.
Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity.
4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft 12.0 m/40.0 ft 13.5 m/45.0 ft
m
ft
13.5 m kg *7050 *7050 11.69
45.0 ft lb *15,700 *15,700 37.57
12.0 m kg *11 670 *11 670 *6670 *6670 13.07
40.0 ft lb *23,650 *23,650 *14,800 *14,800 42.36
10.5 m kg *11 890 *11 890 *10 330 9920 *6490 *6490 14.09
35.0 ft lb *25,950 *25,950 *19,650 *19,650 *14,350 *14,350 45.90
9.0 m kg *12 300 *12 300 *11 360 9920 *6430 6370 14.85
30.0 ft lb *26,750 *26,750 *24,800 21,100 *14,200 *14,200 48.52
7.5 m kg *14 700 *14 700 *12 980 12 750 *11 730 9690 *10 490 7300 *6480 5640 15.39
25.0 ft lb *31,800 *31,800 *28,150 27,350 *25,500 20,650 *19,400 15,400 *14,300 12,550 50.39
6.0 m kg *24 820 *24 820 *19 340 *19 340 *16 030 *16 030 *13 820 12 150 *12 240 9340 *11 080 7150 *6630 5150 15.75
20.0 ft lb *53,150 *53,150 *41,600 *41,600 *34,600 34,550 *29,900 26,100 *26,550 19,950 *24,050 15,150 *14,600 11,400 51.60
4.5 m kg *27 080 *27 080 *21 550 20 010 *17 410 14 970 *14 700 11 480 *12 800 8920 *11 380 6920 *6880 4830 15.92
15.0 ft lb *61,600 60,350 *46,400 43,250 *37,550 32,250 *31,800 24,650 *27,700 19,100 24,600 14,700 *15,150 10,700 52.23
3.0 m kg *23 350 18 370 *18 610 13 950 *15 510 10 820 *13 310 8480 11 230 6660 *7230 4670 15.93
10.0 ft lb *50,350 39,650 *40,200 30,050 *33,500 23,250 *28,800 18,150 24,050 14,200 *15,900 10,300 52.28
1.5 m kg *24 410 17 160 *19 460 13 100 *16 110 10 240 13 490 8090 10 970 6410 *7710 4660 15.78
5.0 ft lb *52,750 37,000 *42,050 28,200 *34,800 22,000 28,950 17,350 23,500 13,650 *17,000 10,250 51.78
Ground kg *12 660 *12 660 *24 670 16 440 *19 840 12 500 16 350 9790 13 160 7780 10 760 6220 *8350 4800 15.45
Line lb *29,950 *29,950 *53,400 35,400 *42,900 26,900 35,150 21,000 28,250 16,650 23,100 13,300 *18,400 10,600 50.69
–1.5 m kg *17 640 *17 640 *24 210 16 100 *19 710 12 150 16 040 9500 12 940 7570 10 650 6110 9080 5130 14.94
–5.0 ft lb *40,950 *40,950 *52,450 34,650 *42,600 26,100 34,450 20,400 27,800 16,250 22,850 13,050 20,050 11,300 48.99
–3.0 m kg *14 820 *14 820 *24 180 23 160 *23 110 16 050 *19 020 12 010 *15 780 9370 12 850 7500 *9090 5700 14.29
–10.0 ft lb *33,850 *33,850 *55,750 49,700 *50,050 34,500 *41,100 25,800 *34,050 20,150 27,650 16,100 *20,000 12,600 46.60
–4.5 m kg *21 960 *21 960 *25 660 23 560 *21 340 16 220 *17 700 12 080 *14 640 9420 *11 560 7580 *8580 6640 13.27
–15.0 ft lb *50,000 *50,000 *55,600 50,600 *46,100 34,850 *38,150 25,950 *31,400 20,250 *25,150 16,300 *18,850 14,750 43.38
–6.0 m kg *25 980 *25 980 *22 280 *22 280 *18 750 16 600 *15 560 12 350 *12 610 9660
–20.0 ft lb *56,150 *56,150 *48,050 *48,050 *40,300 35,750 *33,300 26,600 *26,650 20,850
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤ ➤ ➤
➤
➤
➤
➤ ➤ ➤ ➤ ➤
➤
➤
➤
BOOM – 10 m (32'10")
STICK – 4400 mm (14'5") BUCKET – 1374 mm (54") GP with HD long tips
SHOES – 900 mm (36") double grouser UNDERCARRIAGE – Long
HEAVY LIFT – On
