25 320D LRR Hydraulic Excavator specifications
STICK – 2.5 m (8'3")
BUCKET – No Bucket, Bare Quick Coupler UNDERCARRIAGE – Long
SHOES – 800 mm (32") triple grouser BOOM – 5.7 m (18'9")
HEAVY LIFT – ON
Reach Boom Lift Capacities for 6 Metric Ton Counterweight
1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft) 9.0 m (30.0 ft)
m
ft
9.0 m kg
30.0 ft lb
7.5 m kg *4150 *4150 *3850 *3850 6.06
25.0 ft lb *8,600 *8,600 19.49
6.0 m kg *4950 *4950 *3550 *3550 7.21
20.0 ft lb *10,850 *10,850 *7,850 *7,850 23.47
4.5 m kg *5450 5300 *5100 3700 *3500 3400 7.92
15.0 ft lb *11,850 11,450 *10,950 7,950 *7,700 7,450 25.89
3.0 m kg *8100 7850 *6300 5100 *5450 3600 *3600 3100 8.29
10.0 ft lb *17,400 16,850 *13,650 10,950 *11,900 7,750 *7,900 6,750 27.18
1.5 m kg *9800 7350 *7150 4850 5700 3500 *3850 2950 8.38
5.0 ft lb *21,150 15,800 *15,500 10,450 12,200 7,550 *8,450 6,500 27.49
Ground kg *6100 *6100 *10 750 7050 *7800 4700 5600 3450 *4300 3000 8.19
Line lb *14,000 *14,000 *23,250 15,200 16,800 10,100 12,050 7,350 *9,500 6,650 26.88
–1.5 m kg *6750 *6750 *10 950 *10 950 *10 850 7000 7750 4650 5550 3400 *5150 3300 7.71
–5.0 ft lb *15,050 *15,050 *24,850 *24,850 *23,450 15,000 16,600 9,950 12,000 7,300 *11,350 7,200 25.26
–3.0 m kg *11 750 *11 750 *14 350 13 750 *10 100 7050 *7450 4650 *6150 3900 6.87
–10.0 ft lb *26,350 *26,350 *31,050 29,450 *21,800 15,150 *16,000 10,050 *13,550 8,600 22.42
–4.5 m kg *11 350 *11 350 *8100 7250 *6200 5450 5.50
–15.0 ft lb *24,250 *24,250 *17,200 15,650 *13,650 12,350 17.77
–6.0 m kg
–20.0 ft lb
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
Load at Maximum
Reach – Coupler Curled Load Point
Height Load Radius
Over Front Load Radius
Over Side ➤
➤
➤ ➤
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above
lifting capacities.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
