21 320D LRR Hydraulic Excavator specifications
STICK – 2.9 m (9'6")
BUCKET – No Bucket, Bare Quick Coupler UNDERCARRIAGE – Long
SHOES – 800 mm (32") triple grouser BOOM – 5.7 m (18'7")
HEAVY LIFT – ON
1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft)
m
ft
7.5 m kg *3200 *3200 6.60
25.0 ft lb *7,150 *7,150 21.29
6.0 m kg *3700 *3700 *3000 *3000 7.67
20.0 ft lb *6,600 *6,600 24.97
4.5 m kg *5100 *5100 *4800 3800 *2950 *2950 8.33
15.0 ft lb *11,050 *11,050 *10,500 8,150 *6,500 *6,500 27.26
3.0 m kg *11 650 *11 650 *7500 *7500 *5950 5200 *5200 3700 *3050 2900 8.69
10.0 ft lb *24,750 *24,750 *16,150 *16,150 *12,900 11,200 *11,350 7,950 *6,650 6,400 28.48
1.5 m kg *9350 7550 *6900 4950 *5700 3600 *3200 2800 8.77
5.0 ft lb *20,200 16,200 *14,950 10,700 *12,250 7,650 *7,050 6,150 28.79
Ground kg *6850 *6850 *10 550 7200 *7650 4750 5650 3500 *3600 2850 8.60
Line lb *15,650 *15,650 *22,800 15,500 *16,500 10,250 12,200 7,450 *7,850 6,250 28.20
–1.5 m kg *6250 *6250 *10 400 *10 400 *10 850 7100 7850 4650 5600 3450 *4200 3050 8.14
–5.0 ft lb *14,000 *14,000 *23,600 *23,600 *23,550 15,200 16,800 10,050 12,100 7,350 *9,250 6,750 26.67
–3.0 m kg *10 350 *10 350 *15 150 13 800 *10 400 7100 *7650 4600 *5400 3550 7.35
–10.0 ft lb *23,250 *23,250 *32,750 29,550 *22,450 15,250 *16,500 9,950 *11,950 7,850 23.99
–4.5 m kg *12 550 *12 550 *8850 7250 *6200 4800 *6000 4750 6.09
–15.0 ft lb *26,950 *26,950 *18,900 15,600 *13,250 10,600 19.72
Load at
Maximum Reach Load Point
Height Load Radius
Over Front Load Radius
Over Side
Reach Boom Lift Capacities for 7 Metric Ton Counterweight
STICK – 2.9 m (9'6")
BUCKET – 0.82 m
3 (1.07 yd 3 )
UNDERCARRIAGE – Long
SHOES – 800 mm (32") triple grouser BOOM – 5.7 m (18'7")
HEAVY LIFT – ON
1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft)
m
ft
7.5 m kg *2000 *2000 7.84
25.0 ft lb *4,450 *4,450 25.38
6.0 m kg *3650 3500 *1900 *1900 8.81
20.0 ft lb *4,200 *4,200 28.74
4.5 m kg *4700 *4700 *4400 3450 *1900 *1900 9.38
15.0 ft lb *10,200 *10,200 *9,600 7,350 *4,150 *4,150 30.71
3.0 m kg *11 300 *11 300 *7150 *7150 *5550 4900 *4800 3350 *1950 *1950 9.64
10.0 ft lb *24,000 *24,000 *15,350 *15,350 *12,050 10,500 *10,450 7,200 *4,300 *4,300 31.61
1.5 m kg *9000 7200 *6500 4650 *5300 3250 *2100 2200 9.61
5.0 ft lb *19,350 15,500 *14,050 9,950 *11,450 6,900 *4,650 4,550 31.54
Ground kg *6400 *6400 *10 150 6850 *7250 4450 5300 3150 *2400 2200 9.30
Line lb *14,650 *14,650 *21,850 14,650 *15,650 9,500 11,450 6,700 *5,250 4,800 30.52
–1.5 m kg *5900 *5900 *9950 *9950 *10 450 6750 7500 4350 5250 3100 *2800 2500 8.68
–5.0 ft lb *13,200 *13,200 *22,600 *22,600 *22,600 14,400 16,100 9,300 11,300 6,600 *6,200 5,400 28.44
–3.0 m kg *9950 *9950 *14 650 13 400 *9950 6750 *7250 4350 *3600 3100 7.65
–10.0 ft lb *22,300 *22,300 *31,700 28,650 *21,550 14,450 *15,600 9,300 *8,000 6,800 24.97
–4.5 m kg *12 150 *12 150 *8450 6950 *5800 4500 *4000 *4000 6.02
–15.0 ft lb *26,000 *26,000 *18,050 14,900 *9,300 *9,300 19.59
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above
lifting capacities.
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above
lifting capacities.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
