Lift Capacities
STICK – Standard SHOES – 450 mm (18") BLADE – Down
2.0 m (6.56 ft) 3.0 m (9.84 ft) 4.0 m (13.12 ft)
Max Load Radius
Front Side
Maximum
Reach Front Side Front Side Front Side
3.0 m
9.84 ft
3300 kg*
7,275 lb*
3300 kg*
7,275 lb*
2500 kg*
5,512 lb*
2500 kg*
5,512 lb*
2150 kg*
4,740 lb*
1850 kg
4,079 lb
650 kg*
1,433 lb*
650 kg*
1,433 lb*
5.88 m
19.29 ft
Ground
Line
2600 kg*
5,732 lb*
2600 kg*
5,732 lb*
3800 kg*
8,378 lb*
2600 kg
5,732 lb
2800 kg*
6,173 lb*
1650 kg
3,638 lb
800 kg*
1,764 lb*
800 kg*
1,764 lb*
5.74 m
18.83 ft
–3.0 m
–9.84 ft
3100 kg*
6,834 lb*
3100 kg*
6,834 lb*
2150 kg*
4,740 lb*
2150 kg*
4,740 lb*
1850 kg*
4,079 lb*
1850 kg*
4,079 lb*
3.26 m
10.70 ft
STICK – Standard SHOES – 600 mm (24") BLADE – Down
3.0 m
9.84 ft
3300 kg*
7,275 lb*
3300 kg*
7,275 lb*
2500 kg*
5,512 lb*
2500 kg*
5,512 lb*
2150 kg*
4,740 lb*
1950 kg
4,299 lb
650 kg*
1,433 lb*
650 kg*
1,433 lb*
5.88 m
19.29 ft
Ground
Line
2600 kg*
5,732 lb*
2600 kg*
5,732 lb*
3800 kg*
8,378 lb*
2700 kg
5,952 lb
2800 kg*
6,173 lb*
1750 kg
3,858 lb
800 kg*
1,764 lb*
800 kg*
1,764 lb*
5.74 m
18.83 ft
–3.0 m
–9.84 ft
3100 kg*
6,834 lb*
3100 kg*
6,834 lb*
2150 kg*
4,740 lb*
2150 kg*
4,740 lb*
1850 kg*
4,079 lb*
1850 kg*
4,079 lb*
3.26 m
10.70 ft
STICK – Long SHOES – 450 mm (18") BLADE – Down
3.0 m
9.84 ft
2050 kg*
4,519 lb*
2050 kg*
4,519 lb*
1850 kg*
4,079 lb*
1850 kg*
4,079 lb*
700 kg*
1,543 lb*
700 kg*
1,543 lb*
6.40 m
21.00 ft
Ground
Line
3650 kg*
8,047 lb*
2550 kg
5,622 lb
2700 kg*
5,952 lb*
1650 kg
3,638 lb
850 kg*
1,874 lb*
800 kg
1,764 lb
6.27 m
20.57 ft
–3.0 m
–9.84 ft
4000 kg*
8,818 lb*
4000 kg*
8,818 lb*
2800 kg*
6,173 lb*
2550 kg
5,622 lb
1300 kg*
2,866 lb*
1300 kg*
2,866 lb*
3.97 m
13.02 ft
STICK – Long SHOES – 600 mm (24") BLADE – Down
3.0 m
9.84 ft
2050 kg*
4,519 lb*
2050 kg*
4,519 lb*
1850 kg*
4,079 lb*
1850 kg*
4,079 lb*
700 kg*
1,543 lb*
700 kg*
1,543 lb*
6.40 m
21.00 ft
Ground
Line
3650 kg*
8,047 lb*
2700 kg
5,952 lb
2700 kg*
5,952 lb*
1750 kg
3,858 lb
850 kg*
1,874 lb*
850 kg*
1,874 lb*
6.27 m
20.57 ft
–3.0 m
–9.84 ft
4000 kg*
8,818 lb*
4000 kg*
8,818 lb*
2800 kg*
6,173 lb*
2700 kg
5,952 lb
1300 kg*
2,866 lb*
1300 kg*
2,866 lb*
3.97 m
13.02 ft
* Limited by hydraulic capacity rather than tipping load.
The above loads are in compliance with hydraulic excavator lift capacity rating standard SAE J1097 DEC2005 and do exceed 87% of hydraulic lifting capacity or 75%
of tipping load.
Weight of all lifting accessories must be deducted from the above lifting capacities.
Lifting capacities are based on the machine standing on a firm, uniform supporting surface.
307D Specifications
