300HF..L Series
Standard Recovery Diodes
(Stud Version), 300 A
Vishay High Power Products
ORDERING INFORMATION TABLE
Device code
5 1 3 2 4 6 7
300 HF 40 P V L 1
1 - Current rating (300 = 300 A)
2 - Diode diffused
3 - Voltage ratings
4 - P = 3/4 UNF
M = Metric M16 x 1.5
5 - Glass-metal seal
6 - L = Low V
F
7 - 1 = Lead 150 mm
2 = Lead 200 mm
Note: For “M” type contact factory
40 = 400 V
60 = 600 V
LINKS TO RELATED DOCUMENTS
Dimensions http://www.vishay.com/doc?95341
