300HF..L Series
Standard Recovery Diodes
(Stud Version), 300 A
Vishay High Power Products
Fig. 1 - Current Ratings Characteristics
Fig. 2 - Current Ratings Characteristics
Fig. 3 - Forward Power Loss Characteristics
Fig. 4 - Forward Power Loss Characteristics
Fig. 5 - Maximum Non-Repetitive Surge Current
Fig. 6 - Maximum Non-Repetitive Surge Current
Average Forward Current (A)
Maximum Allowable Case Temperature (°C)
80
90
100
110
120
130
140
150
160
170
180
0 50 100 150 200 250 300 350 400
30°
60°
90°
120°
180°
Conduction Angle
RthJC (DC) = 0.17 K/W
300HF...L
Average Forward Current (A)
Maximum Allowable Case Temperature (°C)
80
90
100
110
120
130
140
150
160
170
180
0 100 200 300 400 500
30°
60°
90°
180° DC
120°
Conduction Period
RthJC (DC) = 0.17 K/W
300HF...L
Average Forward Current (A)
Maximum Average Forward Power Loss (W)
0
50
100
150
200
250
300
350
400
450
0 50 100 150 200 250 300 350
180°
120°
90°
60°
30°
RMS Limit
Conduction Angle
300HF...L
Tj = 180°C
Average Forward Current (A)
Maximum Average Forward Power Loss (W)
0
50
100
150
200
250
300
350
400
450
0 50 100 150 200 250 300 350
180°
120°
90°
60°
30°
RMS Limit
Conduction Angle
300HF...L
Tj = 180°C
Number Of Equal Amplitude Half Cycle Current Pulses (N)
Peak Half Sine Wave Forward Current (A)
1500
2000
2500
3000
3500
4000
4500
5000
5500
1 10 100
300HF...L
Initial Tj = 180 ° C
@ 60 Hz 0.0083 s
@ 50 Hz 0.0100 s
At Any Rated Load Condition And With
Rated Vrrm Applied Following Surge.
Pulse Train Duration(s)
Peak Half Sine Wave On-state Current (A) 500
1000
1500
2000
2500
3000
3500
4000
4500
5000
5500
6000
0.01 0.1 1 10
300HF...L
Initial Tj = 180 ° C
No Voltage Reapplied
Rated Vrrm Reapplied
Maximum Non Repetitive Surge Current
Versus Pulse Train Duration.
