500 PGP-ST
Aluminum Capacitors
Power General Purpose Screw Terminals
Vishay BCcomponents
Table 3
Table 4
Table 5
ADDITIONAL ELECTRICAL DATA
PARAMETER CONDITIONS VALUE
Voltage
Surge voltage
≥ 400 V versions
U
s
= 1.1 x U
R
Reverse voltage U
rev
≤ 1 V
Current
Leakage current
After 1 minute at U
R
I
L1
≤ 0.006 C
R
x U
R
+ 4 µA
After 5 minutes at U
R
I
L5
≤ 0.002 C
R
x U
R
+ 4 µA
Inductance
Equivalent series inductance (ESL)
Case Ø D = 50 mm typ. 16 nH
Case Ø D = 65 mm typ. 19 nH
Case Ø D = 76 mm typ. 20 nH
Case Ø D = 90 mm typ. 20 nH
MULTIPLIER OF RIPPLE CURRENT (I
R
) AS A FUNCTION OF FREQUENCY
FREQUENCY (Hz)
I
R
MULTIPLIER
500
60 0.70
100 0.95
120 1.00
500 1.20
1000 1.30
≥ 10 000 1.40
MULTIPLIER OF RIPPLE CURRENT (I
R
) AS A FUNCTION OF TEMPERATURE
TEMPERATURE (°C) I
R
MULTIPLIER
40 2.7
60 2.0
70 1.7
85 1.0
TEST PROCEDURES AND REQUIREMENTS
TEST PROCEDURE
(quick reference)
REQUIREMENTS
NAME OF TEST REFERENCE
Endurance IEC 60384-4/
EN130300
subclause 4.13 T
amb
= 85 °C; U
R
applied;
2000 hours
ΔC/C: ± 10 %
ESR
≤ 1.3 x spec. limit
Z ≤ 2 x spec. limit
I
L5
≤ spec. limit
Useful life CECC 30301
subclause 1.8.1 T
amb
= 85 °C; U
R
and I
R
applied;
2000 hours
ΔC/C: ± 30 %
ESR
≤ 3 x spec. limit
Z
≤ 3 x spec. limit
I
L5
≤ spec. limit
no short or open circuit,
no visible damage
total failure percentage:
≤ 3 %
Shelf life
(storage at
high temperature) IEC 60384-4/
EN130300
subclause 4.17 T
amb
= 85 °C; no voltage applied;
500 hours
After test: U
R
to be applied for 30 minutes,
24 hours to 48 hours before measurement
ΔC/C: ± 10 %
ESR
≤ 1.2 x spec. limit
I
L5
≤ 2 x spec. limit
