500 PGP-ST
Vishay BCcomponents Aluminum Capacitors
Power General Purpose Screw Terminals
www.vishay.com For technical questions, contact: [email protected] Document Number: 28390
166 Revision: 25-May-09
Table 2
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
100 Hz
(µF)
NOMINAL
CASE
SIZE
Ø D x L
(mm)
I
R
120 Hz
85 °C
(A)
I
R
120 Hz
40 °C
(A)
I
L5
5 min
(mA)
ESR
max.
120 Hz
(m
Ω)
Z
max.
10 kHz
(m
Ω)
HIGH POST
M5 DISC
HIGH CURRENT
M6 DISC
ORDERING
CODE ST
MAL2500.......
ORDERING
CODE STB
MAL2500.......
ORDERING
CODE ST
MAL2500.......
ORDERING
CODE STB
MAL2500.......
400
1000 50 x 80 4.2 11.2 0.80 125 98 26102E3 66102E3 - -
1200 50 x 80 4.5 12.0 0.96 107 85 16122E3 56122E3 - -
1500 50 x 105 5.1 14.1 1.20 86 68 16152E3 56152E3 - -
1800 50 x 105 5.6 15.1 1.44 73 59 16182E3 56182E3 - -
2200 50 x 105 6.3 17.1 1.76 58 46 16222E3 56222E3 - -
2200 65 x 105 7.4 19.9 1.76 58 46 26222E3 66222E3 46222E3 86222E3
2700 65 x 105 7.9 21.5 2.16 49 39 16272E3 56272E3 36272E3 76272E3
3300 65 x 105 8.9 24.0 2.64 39 31 16332E3 56332E3 36332E3 76332E3
3900 65 x 105 9.4 25.5 3.12 34 28 16392E3 56392E3 36392E3 76392E3
4700 76 x 105 11.1 30.0 3.76 30 25 16472E3 56472E3 36472E3 76472E3
5600 76 x 114 12.1 32.6 4.48 26 21 16562E3 56562E3 36562E3 76562E3
6800 76 x 146 13.6 36.6 5.44 21 18 16682E3 56682E3 36682E3 76682E3
8200 90 x 146 17.7 47.7 6.56 16 13 - - 36822E3 76822E3
10 000 76 x 220 17.0 45.8 8.00 15 12 16103E3 56103E3 36103E3 76103E3
10 000 90 x 146 19.3 52.2 8.00 13 11 - - 46103E3 86103E3
12 000 76 x 220 17.8 48.1 9.60 13 11 16123E3 56123E3 36123E3 76123E3
15 000 90 x 220 23.6 63.7 12.00 9 8 - - 36153E3 76153E3
420
1000 50 x 80 4.3 11.5 0.84 105 74 14102E3 54102E3 - -
1200 50 x 80 4.6 12.4 1.01 90 65 14122E3 54122E3 - -
1500 50 x 105 5.3 14.4 1.26 72 52 14152E3 54152E3 - -
1800 50 x 105 5.7 15.3 1.52 62 46 14182E3 54182E3 - -
2200 65 x 105 7.5 20.4 1.85 49 35 14222E3 54222E3 34222E3 74222E3
2700 65 x 105 8.1 21.9 2.27 42 31 14272E3 54272E3 34272E3 74272E3
3300 65 x 105 9.1 24.6 2.78 33 24 14332E3 54332E3 34332E3 74332E3
3900 76 x 105 10.7 28.8 3.28 29 22 14392E3 54392E3 34392E3 74392E3
4700 76 x 114 11.7 31.5 3.95 25 19 14472E3 54472E3 34472E3 74472E3
6800 76 x 146 13.8 37.2 5.72 18 14 14682E3 54682E3 34682E3 74682E3
8200 90 x 146 17.6 47.6 6.89 14 10 - - 34822E3 74822E3
10 000 76 x 220 17.3 46.6 8.40 13 10 14103E3 54103E3 34103E3 74103E3
15 000 90 x 220 24.1 65.0 12.60 8 6 - - 34153E3 74153E3
450
1000 50 x 80 4.2 11.3 0.90 126 88 17102E3 57102E3 - -
1200 50 x 80 4.5 12.1 1.08 100 76 17122E3 57122E3 - -
1500 50 x 105 5.3 14.2 1.35 79 61 17152E3 57152E3 - -
1800 50 x 105 5.9 15.9 1.62 64 48 17182E3 57182E3 - -
2200 65 x 105 7.4 20.0 1.98 54 41 17222E3 57222E3 37222E3 77222E3
2700 65 x 105 8.3 22.5 2.43 43 33 17272E3 57272E3 37272E3 77272E3
3300 76 x 105 9.9 26.8 2.97 37 28 17332E3 57332E3 37332E3 77332E3
3900 76 x 105 10.5 28.4 3.51 32 25 17392E3 57392E3 37392E3 77392E3
4700 76 x 114 11.5 31.0 4.23 28 22 17472E3 57472E3 37472E3 77472E3
5600 76 x 146 12.8 34.6 5.04 23 18 17562E3 57562E3 37562E3 77562E3
6800 90 x 146 16.6 44.8 6.12 17 13 - - 37682E3 77682E3
8200 76 x 220 16.0 43.3 7.38 16 13 17822E3 57822E3 37822E3 77822E3
10 000 76 x 220 17.0 45.8 9.00 14 11 17103E3 57103E3 37103E3 77103E3
12 000 90 x 220 22.1 59.5 10.80 10 8 - - 37123E3 77123E3
