Page 9
051/053 PEC-PW
Vishay BCcomponents
Aluminum Capacitors
Power Economic Printed Wiring
www.vishay.com
For technical questions, contact: [email protected]
Document Number: 28346
8
Revision: 14-Aug-08
IMPEDANCE (Z)
Fig.20 Typical impedance as a function of frequency.
T
amb
(20 °C)
10
6
10
5
10
4
10
3
10
2
10
10
7
f (Hz)
10
2
10
1
Z
(
Ω
)
10
-2
10
-1
1
2
3
4
5
6
7
8
Curve 1: 220 µF, 385 V
Curve 2: 4700 µF, 200 V
Curve 3: 2200 µF, 100 V
Curve 4: 6800µF, 63 V
Curve 5: 10 000 µF, 40 V
Curve 6: 15 000 µF, 25 V
Curve 7: 22 000 µF, 16 V
Curve 8: 33 000 µF, 10 V
Case Ø D x L = 35 x 50 mm
and 35 x 40 mm
Fig.21 Typical impedance as a function of frequency.
T
amb
(20 °C)
10
6
10
5
10
4
10
3
10
2
10
10
7
f (Hz)
10
2
10
1
Z
(
Ω
)
10
-1
10
-2
1
2
3
4
5
6
7
8
Curve 1: 330 µF, 385 V
Curve 2: 680 µF, 200 V
Curve 3: 3300 µF, 100 V
Curve 4: 10 000µF, 63 V
Curve 5: 15 000 µF, 40 V
Curve 6: 22 000 µF, 25 V
Curve 7: 33 000 µF, 16 V
Curve 8: 47 000 µF, 10 V
Case Ø D x L = 40 x 40 mm
T
amb
(20 °C)
10
6
10
5
10
4
10
3
10
2
10
10
7
f (Hz)
10
2
10
1
Z
(
Ω
)
10
-2
10
-1
1
2
3
4
5
6
7
8
Curve 1: 470 µF, 385 V
Curve 2: 1000 µF, 200 V
Curve 3: 47 00 µF, 100 V
Curve 4: 22 000 µF, 40 V
Curve 5: 33 000 µF, 25 V
Curve 6: 47 000 µF, 16 V
Curve 7: 68 000 µF, 10 V
Case Ø D x L = 40 x 50 mm
Fig.22 Typical impedance as a function of frequency.
Fig.23 Typical impedance as a function of frequency.
T
amb
(20 °C)
10
6
10
5
10
4
10
3
10
2
10
10
7
f (Hz)
10
2
10
1
Z
(
Ω
)
10
10
-2
1
2
3
4
5
6
7
Curve 1: 680 µF, 385 V
Curve 2: 1500 µF, 200 V
Curve 3: 6800 µF, 100 V
Curve 4: 15 000µF, 63 V
Curve 5: 33 000 µF, 40 V
Curve 6: 47 000 µF, 25 V
Curve 7: 68 000 µF, 16 V
Case Ø D x L = 40 x 100 mm
Fig.24 Typical impedance as a function of frequency.
T
amb
(20 °C)
10
6
10
5
10
4
10
3
10
2
10
10
7
f (Hz)
10
2
10
1
Z
(
Ω
)
10
10
-2
1
2
3
4
5
6
7
8
Curve 1: 1000 µF, 385 V
Curve 2: 2200 µF, 200 V
Curve 3: 10 000 µF, 100 V
Curve 4: 22 000 µF, 63 V
Curve 5: 47 000 µF, 40 V
Curve 6: 68 000 µF, 25 V
Curve 7: 100 000 µF, 16 V
Case Ø D x L = 40 x 100 mm
