www.vishay.com For technical questions, contact: [email protected] Document Number: 93718
4 Revision: 15-May-08
ST1280C..K Series
Vishay High Power Products Phase Control Thyristors
(Hockey PUK Version),
2310 A
Fig. 1 - Current Ratings Characteristics
Fig. 2 - Current Ratings Characteristics
Fig. 3 - Current Ratings Characteristics
Fig. 4 - Current Ratings Characteristics
Fig. 5 - On-State Power Loss Characteristics
Fig. 6 - On-State Power Loss Characteristics
Average On-state current (A)
Maximum Allowable Heatsink Temperature (
°C)
40
50
60
70
80
90
100
110
120
130
0 400 800 1200 1600
30˚
60˚
90˚
120˚
180˚
Conduction Angle
ST1280C..K Series
(Single Side Cooled)
R (DC) = 0.042 K/W
thJ-hs
Average On-state current (A)
Maximum Allowable Heatsink Temperature (
°C)
20
30
40
50
60
70
80
90
100
110
120
130
0 500 1000 1500 2000 2500
DC
30˚
60˚
90˚
120˚
180˚
Conduction Period
ST1280C..K Series
(Single Side Cooled)
R (DC) = 0.042 K/W thJ-hs
Average On-state Current (A)
Maximum Allowable Heatsink Temperature (
°C)
30
40
50
60
70
80
90
100
110
120
130
0 500 1000 1500 2000 2500 3000
30˚
60˚
90˚
120˚
180˚
Conduction Angle
ST1280C..K Series
(Double Side Cooled)
R (DC) = 0.021 K/W thJ-hs
Average On-state Current (A)
Maximum Allowable Heatsink Temperature (
°C)
20
30
40
50
60
70
80
90
100
110
120
130
0 1000 2000 3000 4000 5000
DC
30˚
60˚
90˚
120˚
180˚
Conduction Period
ST1280C..K Series
(Double Side Cooled)
R (DC) = 0.021 K/W
thJ-hs
Average On-state Current (A)
Maximum Average On-state Power Loss (W)
0
400
800
1200
1600
2000
2400
2800
3200
3600
0 500 1000 1500 2000 2500 3000
180˚
120˚
90˚
60˚
30˚
RMS Limit
Conduction Angle
ST1280C..K Series
T = 125˚C
J
Average On-state Current (A)
Maximum Average On-state Power Loss (W)
0
500
1000
1500
2000
2500
3000
3500
4000
4500
5000
0 1000 2000 3000 4000 5000
DC
180˚
120˚
90˚
60˚
30˚
RMS Limit
Conduction Period
ST1280C..K Series
T = 125˚C
J
