www.vishay.com For technical questions, contact: [email protected] Document Number: 93718
2 Revision: 15-May-08
ST1280C..K Series
Vishay High Power Products Phase Control Thyristors
(Hockey PUK Version),
2310 A
ON-STATE CONDUCTION
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum average on-state current
at heatsink temperature
I
T(AV)
180° conduction, half sine wave
Double side (single side) cooled 2310 (885) A
55 (85) °C
Maximum RMS on-state current I
T(RMS)
25 °C heatsink temperature double side cooled 4150
A Maximum peak, one-cycle
non-repetitive surge current
I
TSM
t = 10 ms No voltage
reapplied
Sinusoidal half wave,
initial T
J
= T
J
maximum
42 500
t = 8.3 ms 44 500
t = 10 ms 100 % V
RRM
reapplied
35 700
t = 8.3 ms 37 400
Maximum I 2 t for fusing I 2 t
t = 10 ms No voltage
reapplied 9027
kA 2 s
t = 8.3 ms 8241
t = 10 ms 100 % V
RRM
reapplied
6383
t = 8.3 ms 5828
Maximum I 2 √t for fusing
I 2 √t
t = 0.1 to 10 ms, no voltage reapplied 90 270 kA 2 √s
Low level value of threshold voltage V
T(TO)1
(16.7 % x π x I
T(AV)
< I < π x I
T(AV)
), T
J
= T
J
maximum 0.83
V
High level value of threshold voltage V
T(TO)2
(I > π x I
T(AV)
), T
J
= T
J
maximum 0.90
Low level value of on-state slope resistance r
t1
(16.7 % x π x I
T(AV)
< I < π x I
T(AV)
), T
J
= T
J
maximum 0.077
m Ω
High level value of on-state slope resistance r
t2
(I > π x I
T(AV)
), T
J
= T
J
maximum 0.068
Maximum on-state voltage V
TM
I
pk
= 8000 A, T
J
= T
J
maximum, t
p
= 10 ms sine pulse 1.44 V
Maximum holding current I
H
T
J
= 25 °C, anode supply 12 V resistive load
600
mA
Typical latching current I
L
1000
SWITCHING
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum non-repetitive rate of
rise of turned-on current
dI/dt
Gate drive 20 V, 20 Ω, t
r
≤ 1 µs
T
J
= T
J
maximum, anode voltage
≤ 80 % V
DRM
1000 A/µs
Typical delay time t
d
Gate current 1 A, dI
g
/dt = 1 A/µs
V
d
= 0.67 % V
DRM
, T
J
= 25 °C
1.9
µs
Typical turn-off time t
q
I
TM
= 550 A, T
J
= T
J
maximum, dI/dt = 40 A/µs,
V
R
= 50 V, dV/dt = 20 V/µs, gate 0 V 100
Ω, t
p
= 500 µs
200
BLOCKING
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum critical rate of rise of
off-state voltage
dV/dt T
J
= T
J
maximum linear to 80 % rated V
DRM
500 V/µs
Maximum peak reverse and
off-state leakage current I
RRM
,
I
DRM
T
J
= T
J
maximum, rated V
DRM
/V
RRM
applied 100 mA
