Document Number: 93718 For technical questions, contact: [email protected] www.vishay.com
Revision: 15-May-08 1
Phase Control Thyristors
(Hockey PUK Version), 2310 A
ST1280C..K Series
Vishay High Power Products
FEATURES
• Center amplifying gate
• Metal case with ceramic insulator
• International standard case A-24 (K-PUK)
• High profile hockey PUK
• Lead (Pb)-free
TYPICAL APPLICATIONS
• DC motor controls
• Controlled DC power supplies
• AC controllers
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
T(AV)
2310 A
A-24 (K-PUK)
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST CONDITIONS VALUES UNITS
I
T(AV)
2310 A
T
hs
55 °C
I
T(RMS)
4150 A
T
hs
25 °C
I
TSM
50 Hz 42 500
A
60 Hz 44 500
I 2 t
50 Hz 9027
kA 2 s
60 Hz 8240
V
DRM
/V
RRM
400 to 600 V
t
q
Typical 200 µs
T
J
- 40 to 125 °C
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
DRM/
V
RRM
, MAXIMUM REPETITIVE PEAK
AND OFF-STATE VOLTAGE
V
V
RSM
, MAXIMUM
NON-REPETITIVE PEAK VOLTAGE
V
I
DRM/
I
RRM
MAXIMUM
AT T
J
= T
J
MAXIMUM
mA
ST1280C..K
04 400 500
100
06 600 700
