VSK.430..PbF Series
Thyristor/Diode and Thyristor/Thyristor, 430 A
(SUPER MAGN-A-PAK
TM
Power Modules)
Vishay High Power Products
CIRCUIT CONFIGURATION
+
7
(K2)
6 (G2)
-
4
(K1)
5 (G1)
~
1
2
3
+
7 (K2)
6 (G2)
-
~
1
2
3
+
-
4 (K1)
5 (G1)
~
1
2
3
VSKT...
VSKH...
VSKL...
