Powerex, Inc., 173 Pavilion Ln, Youngwood, PA 15697 (412)925-7272 WWW.PWRX.COM
Phase Control Thyristor
3200 Amperes/Up to 1600 Volts
Absolute Maximum Ratings
Characteristics
Symbol
Units
Non-repetitive Transient Peak Reverse Voltage V
RSM
V
RRM
+100V V
RMS On-State Current I
T(RMS)
5025 A
Average Current 180
° Sine Wave, T
C
=76
°C I
T(AV)
3200 A
Peak One Cycle Surge On-State Current (Non-Repetitive)
60Hz I
TSM
44,000 A
Peak One Cycle Surge On-State Current (Non-Repetitive)
50Hz I
TSM
40500 A
Critical Rate-of-Rise of On-State Current (Non-Repetitive) di/dt 300 A/
µs
Critical Rate-of-Rise of On-State Current (Repetitive) di/dt 100 A/ µs
I 2 t for Fusing for One Cycle, 60 Hz I 2 t 8.07x10 6 A 2 s
Peak Gate Power Dissipation P
GM
250 W
Average Gate Power Dissipation P
G(av)
35 W
Operating Temperature T
J
-40 to 125
°C °C
Storage Temperature T
STG
-40 to 150 °C °C
Mounting Force 6000 to 10000
26.6 to 44.4
lb.
kN
TBS716P13.DOC.1/19/2006
Information presented is based upon manufacturers testing and projected
capabilities. This information is subject to change without notice. The
manufacturer makes no claim as to suitability for use, reliability, capability or
future availability of this product.
TBS7
3200A
