Powerex, Inc., 173 Pavilion Ln, Youngwood, PA 15697 (412)925-7272 WWW.PWRX.COM
Phase Control Thyristor
3200 Amperes/Up to 1600 Volts
Ordering Information
Select the complete 12 digit device part number from the table below.
Description:
Powerex Silicon Controlled Rectifiers (SCR) are
designed for phase control applications. These
are all-diffused, hermetic Pow-R-Disc devices
employing the field-proven amplifying gate.
Features:
„ Low On-State Voltage
„ High di/dt Capability
„ High dv/dt Capability
„ Excellent Surge and I
2 t Ratings
Applications:
„ Power Supplies
„ Battery Chargers
„ Motor Controllers
TBS716P13.DOC.12/10/97
TBS7
3200A
Type Voltage
V
DRM
V
RRM
Current
I
T(av)
Turn-Off
t
q
Gate
Current
I
GT
Lead
Code
TBS7 12
14
16
32 0 3 DH
1200 V
1400 V
1600 V
3200 A 350
µs
typical
200 mA 12"
A DIA.
C DIA.
A DIA.
B DIA.
D
E
D
H
A B C D E F G H SYM.
INCHES
MM
.030
0.76
.140
3.56
ANODE
MARKING CATHODE
F DIA. TYP.
G DEEP TYP.
]
]
GATE TERMINAL
FOR .058 INCH /
1.47 MM DIA. NOM.
PIN RECEPTACLE
CATHODE POTENTIAL TERMINAL
FOR .187 INCH / 4.75 MM NOM.
PUSH-ON TYPE TERMINAL
20 O
20 O
CASE NUMBER TBS
2.88
73.2
4.36
110.7
3.95
100.3
.080
2.03
1.010/1.080
25.65/27.43
NOMINAL DIMENSIONS
STRIKE DISTANCE = .62 INCH / 15.7 MM MIN.
CREEPAGE DISTANCE = 1.00 INCH / 25.4 MM MIN.
ALL DIMENSIONS ARE REFERENCE
