Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272 POW-R-BLOK
TM
www.pwrx.com Dual SCR Isolated Module
600 Amperes / Up to 2400 Volts
Revision Date: 09/28/2009
PD43__06
Electrical Characteristics, T
J
=25
°C unless otherwise specified
Characteristics Symbol Test Conditions Min. Max. Units
Repetitive Peak Forward Leakage Current I
DRM
Up to 2400V, T
J
=125
°C
100 mA
Repetitive Peak Reverse Leakage Current I
RRM
Up to 2400V, T
J
=125 °C 100 mA
Peak On-State Voltage V
TM
I
TM
=3000A, T
J
=125 °C 1.75 V
Threshold Voltage, Low-level
Slope Resistance, Low-level V
(TO)1
r
T1
T
J
= 125
°C, I = 15%I
T(AV)
to πI
T(AV)
0.869
0.237
V
m Ω
Threshold Voltage, High-level
Slope Resistance, High-level V
(TO)2
r
T2
T
J
= 125 °C, I = πI
T(AV)
to I
TSM
1.055
0.175
V
m Ω
V
TM
Coefficients, Full Range T
J
= 125 °C, I = 50A to 6kA
V
TM
= A+ B Ln I +C I + D Sqrt I
A =
B =
C =
D = 0.93159
-4.51 E-02
9.95 E-05
1.29 E-02
Minimum dV/dt dV/dt Exponential to 0.67V
DRM
T
j
=125
°C, Gate Open
300 V/ μs
Gate Trigger Current I
GT
T
j
=25 °C, V
D
=12V 200 mA
Gate Trigger Voltage V
GT
T
j
=25 °C, V
D
=12V 4.5 Volts
Non-Triggering Gate Voltage V
GDM
T
j
=125
°C, V
D
= ½ V
DRM
0.15 Volts
Holding Current I
H
300 mA
Peak Forward Gate Current I
GTM
4.0 Amp
Peak Reverse Gate Voltage V
GRM
5 Volts
Maximum Average Gate Power Dissipation P
GM (AVE)
16 Watts
Thermal Characteristics
Characteristics Symbol Max. Units
Thermal Resistance, Junction to Case
RΘ
J-C
Per Module, both conducting
Per Junction, both conducting
0.029
0.058
°C/W
°C/W
Thermal Impedance Coefficients
ZΘ J-C ZΘ J-C = K 1 (1-exp(-t/ t
1 ))
+ K
2
(1-exp(-t/ t
2
))
+ K
3
(1-exp(-t/ t
3
))
+ K 4 (1-exp(-t/ t
4 ))
K 1 = 5.04 E-04
K
2
= 2.31 E-03
K
3
= 2.83 E-03
K 4 =5.24 E-02
t
1 = 2.47 E-03
t
2 = 4.42 E-02
t
3 = 1.370
t
4
= 9.668
Thermal Resistance, Case to Sink Lubricated RΘ
C-S
Per Module 0.009
°C/W
Information presented is based upon manufacturers testing and projected capabilities.
This information is subject to change without notice.
The manufacturer makes no claim as to suitability for use, reliability, capability,
or future availability of this product.
