Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272 POW-R-BLOK
TM
www.pwrx.com Dual SCR Isolated Module
600 Amperes / Up to 2400 Volts
Revision Date: 09/28/2009
PD43__06
Absolute Maximum Ratings
Characteristics Conditions Symbol Units
Repetitive Peak Forward and Reverse Blocking
Voltage V
DRM
& V
RRM
Up to 2400 V
Non-Repetitive Peak Blocking Voltage
(t < 5 msec) V
RSM
V
RRM
+ 100V V
RMS Current AC Switch Configuration
(180
o
Conduction)
180
° Conduction, T
C
=66
°C
180
° Conduction, T
C
=71
°C
180 ° Conduction, T
C
=76 °C
180
° Conduction, T
C
=81
°C
180 ° Conduction, T
C
=86 °C
180
° Conduction, T
C
=90
°C
I
T(RMS)
I
T(RMS)
I
T(RMS)
I
T(RMS)
I
T(RMS)
I
T(RMS)
1665
1550
1440
1330
1220
1110
A
A
A
A
A
A
RMS Current Per SCR
(180
o
Conduction)
180 ° Conduction, T
C
=66 °C
180
° Conduction, T
C
=71
°C
180 ° Conduction, T
C
=76 °C
180
° Conduction, T
C
=81
°C
180 ° Conduction, T
C
=86 °C
180
° Conduction, T
C
=90
°C
I
T(RMS)
I
T(RMS)
I
T(RMS)
I
T(RMS)
I
T(RMS)
I
T(RMS)
1178
1100
1020
942
864
785
A
A
A
A
A
A
Average Forward Current Per SCR
(180
o
Conduction)
180 ° Conduction, T
C
=66 °C
180
° Conduction, T
C
=71
°C
180 ° Conduction, T
C
=76 °C
180
° Conduction, T
C
=81
°C
180
° Conduction, T
C
=86
°C
180 ° Conduction, T
C
=90 °C
I
T(AV)
I
T(AV)
I
T(AV)
I
T(AV)
I
T(AV)
I
T(AV)
750
700
650
600
550
500
A
A
A
A
A
A
Peak One Cycle Surge Current, Non-Repetitive
Tj = 25C, Vr = 0 60 Hz
50 Hz I
TSM
I
TSM
50,890
46,400 A
A
Peak One Cycle Surge Current, Non-Repetitive
Tj = 25C, Vr = Vrrm 60 Hz
50 Hz I
TSM
I
TSM
33,925
30,935 A
A
Peak One Cycle Surge Current, Non-Repetitive
Tj = 125C, Vr = 0 60 Hz
50 Hz I
TSM
I
TSM
44,250
40,350 A
A
Peak One Cycle Surge Current, Non-Repetitive
Tj = 125C, Vr = Vrrm 60 Hz
50 Hz I
TSM
I
TSM
29,500
26,900 A
A
Peak Three Cycle Surge Current, Non-Repetitive 60 Hz, Tj = 125C, Vr = Vrrm I
TSM
23,690 A
Peak Ten Cycle Surge Current, Non-Repetitive 60 Hz, Tj = 125C, Vr = Vrrm I
TSM
18,615 A
I 2 t for Fusing for One Cycle
Tj = 125C, Vr = Vrrm
8.3 milliseconds
10 milliseconds
I 2 t
I 2 t
3.63 x 10
6
3.62 x 10
6
A 2 sec
A 2 sec
Maximum Rate-of-Rise of On-State Current,
(Non-Repetitive) Per JEDEC Standard 397 5.2.2.6 di/dt 400 A/
μs
Maximum Rate-of-Rise of On-State Current,
(Repetitive) Per JEDEC Standard 397 5.2.2.6 di/dt 150 A/
μs
Operating Temperature T
J
-40 to +125 °C
Storage Temperature T
stg
-40 to +150
°C
Max. Mounting Torque, M6 Mounting Screw 132
15
in. – Lb.
Nm
Max. Mounting Torque, M10 Terminal Screw 106
12
in. – Lb.
Nm
Module Weight, Typical 5.33 kg
11.75 lb
V Isolation @ 25C V
rms
3000 V
