Outline Dimensions
www.vishay.com
Vishay Semiconductors
Revision: 03-Aug-11 1 Document Number: 95240
For technical questions within your region: [email protected] , [email protected] , [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
PowerTab ®
DIMENSIONS in millimeters (inches)
15.90 (0.62)
15.60 (0.61)
4.20 (0.16) 4.00 (0.15)
4.95 (0.19) 4.75 (0.18)
5.20 (0.20) 4.95 (0.19)
18.25 (0.71) 18.00 (0.70)
27.65 (1.08) 27.25 (1.07)
39.8 (1.56) 39.6 (1.55)
12.40 (0.48) 12.10 (0.47)
8.45 (0.33) 8.20 (0.32)
15.60 (0.61)
14.80 (0.58)
5.45 REF.
(0.21 REF.)
1.30 (0.05)
1.10 (0.04) 3.09 (0.12)
3.00 (0.11)
1.35 (0.05)
1.20 (0.04)
0.60 (0.02)
0.40 (0.01)
12.20 (0.48)
12.00 (0.47)
Ш 4.20 (Ш 0.16)
Ш 4.00 (Ш 0.15)
Ш 4.20 (Ш 0.16)
Ш 4.00 (Ш 0.15)
Lead 1
Lead 2
Lead assignments
Lead 1 = Cathode
Lead 2 = Anode
