GB15XP120KTPbF
Vishay Semiconductors Three Phase Inverter Module in MTP Package
1200 V NPT IGBT and HEXFRED ® Diodes, 15 A
Fig. 15 - Typical Transfer Characteristics
V
CE
= 50 V; t
p
= 10 μs
Fig. 16 - Typical Diode Forward Characteristics
t
p
= 80 μs
Fig. 17 - Typical Diode I
rr
vs. I
F
T
J
= 125 °C
Fig. 18 - Typical Diode I
rr
vs. R
g
T
J
= 125 °C; I
F
= 10 A
Fig. 19 - Typical Diode I
rr
vs. dI
F
/dt; V
CC
= 600 V;
V
GE
= 15 V; I
CE
= 10 A, T
J
= 125 °C
0 4 8 12 16
0
40
80
120
160
Vge (V)
Ice (A)
Tj = 25°C
Tj = 125°C
0 1 2 3 4
0
10
20
30
40
50
Vf (V)
If
(
A
)
Tj = 25°C
Tj = 125°C
5 10 15 20 25 30 35
5
15
25
35
45
55
If (A)
Irr (
A
)
Rg=4.7 Ω
Rg= 10 Ω
Rg= 22Ω
Rg=47 Ω
0 10 20 30 40 50
15
20
25
30
35
40
45
Rg ( )
Irr (
A
)
400 550 700 850 1000 1150 1300
15
20
25
30
35
40
45
dif/dt (A/µs)
Irr (
A
)
