GB15XP120KTPbF
Vishay Semiconductors Three Phase Inverter Module in MTP Package
1200 V NPT IGBT and HEXFRED ® Diodes, 15 A
ELECTRICAL SPECIFICATIONS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Collector to emitter breakdown voltage V
(BR)CES
V
GE
= 0 V, I
C
= 250 μA 1200 - - V
Temperature coefficient of V
(BR)CES
V
(BR)CES
/ T
J
V
GE
= 0 V, I
C
= 1 mA - 1.11 - V/°C
Collector to emitter voltage V
CE(on)
V
GE
= 15 V, I
C
= 15 A - 2.51 2.70
V
V
GE
= 15 V, I
C
= 30 A - 3.36 3.66
V
GE
= 15 V, I
C
= 15 A, T
J
= 125 °C - 2.94 3.16
V
GE
= 15 V, I
C
= 30 A, T
J
= 125 °C - 4.12 4.46
Gate threshold voltage V
GE(th)
I
C
= 250 μA 4 - 6
Temperature coefficient of
threshold voltage
V
GE(th)
/ T
J
V
CE
= V
GE
, I
C
= 1 mA - - 10 - mV/°C
Forward transconductance g
fe
V
CE
= 25 V, I
C
= 15 A - 12 - S
Collector to emitter leaking current I
CES
V
GE
= 0 V, V
CE
= 1200 V - - 250
μA
V
GE
= 0 V, V
CE
= 1200 V, T
J
= 125 °C - - 1000
Diode forward voltage drop V
FM
I
F
= 15 A, V
GE
= 0 V - 2.13 2.58
V
I
F
= 30 A, V
GE
= 0 V - 2.70 3.33
I
F
= 15 A, V
GE
= 0 V, T
J
= 125 °C - 2.27 2.75
I
F
= 30 A, V
GE
= 0 V, T
J
= 125 °C - 3.06 3.76
Gate to emitter leakage current I
GES
V
GE
= ± 20 V - - ± 250 nA
SWITCHING CHARACTERISTICS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Total gate charge (turn-on) Q
g I
C
= 15 A
V
CC
= 600 V
V
GE
= 15 V
- 98 146
nC Gate to emitter charge (turn-on) Q
ge
- 12 17
Gate to collector charge (turn-on) Q
gc
- 46 69
Turn-on switching loss E
on
I
C
= 15 A, V
CC
= 600 V, V
GE
= 15 V
R
g
= 10
, L = 500 μH, T
J
= 25 °C
Energy losses include tail and
diode reverse recovery
- 0.990 1.485
mJ Turn-off switching loss E
off
- 0.827 1.241
Total switching loss E
ts
- 1.817 2.726
Turn-on switching loss E
on
I
C
= 15 A, V
CC
= 600 V, V
GE
= 15 V
R
g
= 10 , L = 500 μH, T
J
= 125 °C
Energy losses include tail and
diode reverse recovery
- 1.352 2.028
mJ Turn-off switching loss E
off
- 1.138 1.707
Total switching loss E
ts
- 2.490 3.735
Turn-on delay time t
d(on)
I
C
= 15 A, V
CC
= 600 V, V
GE
= 15 V
L = 500 μH, L
S
= 100 nH
R
g
= 10 , T
J
= 125 °C
- 95 143
ns
Rise time t
r
- 18 27
Turn-off delay time t
d(off)
- 134 200
Fall time t
f
- 227 341
Reverse BIAS safe operating area RBSOA
T
J
= 150 °C, I
C
= 60 A
R
g
= 10 , V
GE
= 15 V to 0
Fullsquare
Short circuit safe operating area SCSOA
V
CC
= 600 V, V
GE
= + 15 V to 0
T
J
= 150 °C, V
P
= 1200 V, R
g
= 10 
10 - - μs
Input capacitance C
ies V
GE
= 0 V
V
CC
= 30 V
f = 1 MHz
- 1302 1953
pF Output capacitance C
oes
- 717 1076
Reverse transfer capacitance C
res
- 38 57
Diode reverse recovery energy E
rec I
C
= 15 A, V
CC
= 600 V, V
GE
= 15 V
L = 500 μH, L
S
= 100 nH
R
g
= 10 , T
J
= 125 °C
- 819 - μJ
Diode reverse recovery time t
rr
- 96 - ns
Diode peak reverse current I
rr
- 35 - A
