C&H Technology PS21962-4S - Manual (Page 11)

PS21962-4S
Intellimod™ Module
Dual-In-Line Intelligent Power Module
5 Amperes/600 Volts
Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272
10 Rev.12/09
10 0 10 1
10 1
COLLECTOR CURRENT, I
C
, (AMPERES)
SWITCHING TIME, t
c(on)
, (ns)
SWITCHING TIME (ON) VS.
COLLECTOR CURRENT
(TYPICAL - INVERTER PART P-SIDE)
10 2
10 3
10 0 10 1
10 1
COLLECTOR CURRENT, I
C
, (AMPERES)
SWITCHING TIME, t
c(off)
, (ns)
SWITCHING TIME (OFF) VS.
COLLECTOR CURRENT
(TYPICAL - INVERTER PART P-SIDE)
10 2
10 3
V
CC
= 300V
V
CIN
= 0 ⇔ 5V
V D = V DB = 15V
T j = 25°C
T
j
= 125°C
INDUCTIVE LOAD
V
CC
= 300V
V
CIN
= 0 ⇔ 5V
V D = V DB = 15V
T j = 25°C
T
j
= 125°C
INDUCTIVE LOAD
