ST110SPbF Series
Phase Control Thyristors
(Stud Version), 110 A
Vishay High Power Products
Note
• The table above shows the increment of thermal resistance R
thJC
when devices operate at different conduction angles than DC
TRIGGERING
PARAMETER SYMBOL TEST CONDITIONS
VALUES
UNITS
TYP. MAX.
Maximum peak gate power P
GM
T
J
= T
J
maximum, t
p
≤ 5 ms
5
W
Maximum average gate power P
G(AV)
T
J
= T
J
maximum, f = 50 Hz, d% = 50 1
Maximum peak positive gate current I
GM
T
J
= T
J
maximum, t
p
≤ 5 ms
2.0 A
Maximum peak positive gate voltage + V
GM
20
V
Maximum peak negative gate voltage - V
GM
5.0
DC gate current required to trigger I
GT
T
J
= - 40 °C
Maximum required gate trigger/
current/voltage are the lowest
value which will trigger all units
6 V anode to cathode applied
180 -
mA T
J
= 25 °C 90 150
T
J
= 125 °C 40 -
DC gate voltage required to trigger V
GT
T
J
= - 40 °C 2.9 -
V T
J
= 25 °C 1.8 3.0
T
J
= 125 °C 1.2 -
DC gate current not to trigger I
GD
T
J
= T
J
maximum
Maximum gate current/voltage
not to trigger is the maximum
value which will not trigger any
unit with rated V
DRM
anode to
cathode applied
10 mA
DC gate voltage not to trigger V
GD
0.25 V
THERMAL AND MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum operating junction
temperature range
T
J
- 40 to 125
°C
Maximum storage temperature range T
Stg
- 40 to 150
Maximum thermal resistance,
junction to case
R
thJC
DC operation 0.195
K/W
Maximum thermal resistance,
case to heatsink
R
thCS
Mounting surface, smooth, flat and greased 0.08
Mounting torque, ± 10 %
Non-lubricated threads 15.5 (137) Nm
(lbf · in) Lubricated threads 14 (120)
Approximate weight 130 g
Case style See dimensions - link at the end of datasheet TO-209AC (TO-94)
ΔR
thJC
CONDUCTION
CONDUCTION ANGLE SINUSOIDAL CONDUCTION RECTANGULAR CONDUCTION TEST CONDITIONS UNITS
180° 0.035 0.025
T
J
= T
J
maximum K/W
120° 0.041 0.042
90° 0.052 0.056
60° 0.076 0.079
30° 0.126 0.127
