Document Number: 94393 For technical questions, contact: [email protected] www.vishay.com
Revision: 30-Apr-08 1
Phase Control Thyristors
(Stud Version), 110 A
ST110SPbF Series
Vishay High Power Products
FEATURES
• Center gate
• International standard case TO-209AC (TO-94)
• Compression bonded encapsulation for heavy
duty operations such as severe thermal cycling
• Hermetic glass-metal case with ceramic insulator
(Glass-metal seal over 1200 V)
• Lead (Pb)-free
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• DC motor controls
• Controlled DC power supplies
• AC controllers
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
T(AV)
110 A
TO-209AC (TO-94)
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST CONDITIONS VALUES UNITS
I
T(AV)
110 A
T
C
90 °C
I
T(RMS)
175
A
I
TSM
50 Hz 2700
60 Hz 2830
I 2 t
50 Hz 36.4
kA 2 s
60 Hz 33.2
V
DRM
/V
RRM
400 to 1600 V
t
q
Typical 100 µs
T
J
- 40 to 125 °C
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
DRM
/V
RRM
, MAXIMUM REPETITIVE PEAK
AND OFF-STATE VOLTAGE
V
V
RSM
, MAXIMUM
NON-REPETITIVE PEAK VOLTAGE
V
I
DRM
/I
RRM
MAXIMUM
AT T
J
= T
J
MAXIMUM
mA
ST110S
04 400 500
20
08 800 900
12 1200 1300
16 1600 1700
