Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697-1800 (724) 925 7272 www.pwrx.com
R9G0
Rectifier Diode
1800 Amperes / Up to 3200 Volts
Absolute Maximum Ratings
Conditions Symbol Units
Repetitive Peak Reverse Blocking Voltage V
RRM
up to 3200 V
Non-Repetitive Peak Reverse Blocking Voltage V
RSM
V
RRM
+ 100 V
RMS Forward Current I
F(RMS)
2825 A
Average Forward Current 180 ° Conduction, T
C
=110 ° C I
F(AV)
1800 A
Peak Half Cycle Non-Repetitive Surge Current t = 8.3mS, 100%V RRM reapplied I FSM 21,500 A
Peak Half Cycle Non-Repetitive Surge Current t = 10mS, 100%V
RRM
reapplied I
FSM
19,600 A
I
2
t for Fusing for One Cycle I
2
t 1.925x10
6
A
2
-sec
I 2 t of Package t = 8.3mS I 2 t 90x10 6 A 2 -sec
Operating Junction Temperature T
J
-40 to +175 ° C
Storage Temperature T
stg
-40 to +190 ° C
Mounting Force - - - - 5000 to 6000
2270 to 2700
lb.
kg
Module Weight, Typical - - - - 454
1.0
g
lbs
R9G0
1800A
06-16-2010
