Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697-1800 (724) 925 7272 Rectifier Diode
1800 Amperes/Up to 3200 Volts
Ordering Information
Select the complete 10 digit device part number from the table below.
Description:
Powerex General Purpose Rectifiers are
designed with high blocking voltage capability
with low forward on-state voltage to minimize
conduction losses. These are all-diffused,
hermetic Pow-R-Disc devices which can be
mounted using commercially available clamps
and heatsinks..
Features:
n Low On-State Voltage
n Low Thermal Impedance
n Hermetic Packaging
n Excellent Surge and I 2
t Ratings
Applications:
n Power Supplies
n Motor Control
n Free Wheeling Diode
R9G0
1800A
Type Voltage
V
RRM
Current
I
T(av)
Recovery
Time
t
rr
R9G0 12
through
32
18 XX
1200 V
through
3200 V
1800 A 25 µs
typical
06-16-2010
