D-23
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
CS641230
Fast Recovery Single Diode Module
300 Amperes/1200 Volts
Electrical and Thermal Characteristics, Tj = 25°C unless otherwise specified
Characteristics Symbol Test Conditions CS641230 Units
Blocking State Maximums
Reverse Leakage Current, Peak IRRM Tj = 150°C, VRRM = Rated 40 mA
Conducting State Maximums
Peak On-State Voltage VFM IFM = 300A, Tj = 25°C 1.5 Volts
Switching Maximums
Reverse Recovery Time trr IFM = 300A, Tj = 150°C 0.8 ␮ s
di/dt =-600A/ ␮ s, VR = 600V
Reverse Recovery Charge Qrr IFM = 300A, Tj = 150°C 80 ␮ C
di/dt =-600A/ ␮ s, VR = 600V
Thermal Maximums
Thermal Resistance, Junction-to-Case R ␪ (J-C)
Per Module 0.2 °C/Watt
Thermal Resistance, Case-to-Sink (Lubricated) R ␪ (C-S)
Per Module 0.15 °C/Watt
Isolation Resistance, Main Terminal-to-Case — Per Module 10 (minimum) m
Ω
