D-22
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
CS641230
Fast Recovery Single Diode Module
300 Amperes/1200 Volts
Absolute Maximum Ratings
Characteristics Symbol CS641230 Units
Peak Reverse Blocking Voltage VRRM 1200 Volts
Transient Peak Reverse Blocking Voltage (Non-Repetitive), t < 5ms VRSM 1350 Volts
DC Reverse Blocking Voltage VR(DC) 960 Volts
DC Current, TC = 75°C IF(DC) 300 Amperes
Peak Half-Cycle Surge (Non-Repetitive) On-State Current (60Hz) IFSM 3000 Amperes
I2t (for Fusing), 8.3 milliseconds I2t 37500 A2sec
Junction Temperature Tj -40 to 150 °C
Storage Temperature TSTG -40 to 125 °C
Maximum Mounting Torque M5 Mounting Screw — 17 in.-lb.
Maximum Mounting Torque M6 Terminal Screw — 26 in.-lb.
Module Weight (Typical) — 200 Grams
V Isolation VRMS 2500 Volts
