10 Supplement
10 .1 Technical data
General data
316L corresponds to 1.4404 or 1.4435
M aterials, wetted parts
-
P rocess fitting thread G1½ A and 1½ NPT: PVDF, Tri-Clamp 2"
and 3", bolting DN 50 and DN 80: adapter of 316L
-
A ntenna PVDF
-
S eal thread FKM (V iton)
-
S eal, bolting FKM (V iton)
M aterials, non-wetted parts
-
H ousing A luminium die-casting powder coated
-
S eal between housing and housing
cover
NBR ( stainless steel housing), silicone (Alu/plastic
housing)
-
I nspection window in housing cover for
PLICSCOM
P olycarbonate (UL-746-C listed)
-
G round terminal 316T i/316L
W eight depending on process fitting and
housing material
0.7 … 3.4 kg (1.543 … 7.496 lbs)
Output variable
O utput signal 4 … 20 mA/HART (active)
C ycle time min. 1 s (dependent on the parameter setting)
S ignal resolution 1.6 µA
F ailure signal current output (adjustable) mA-value unchanged 20.5 mA, 22 mA, < 3.6 mA
(
adjustable)
M ax. output current 22 mA
L oad
< 500 Ω 3)
D amping (63 % of the input variable) 0 … 999 s, adjustable
F ulfilled NAMUR recommendations NE 43
HART output values
-
1. HART value (Primary Value) D istance to the level
-
2. HART value (Secondary Value) D istance to the level - scaled (for example hl, %)
R esolution, digital > 1 mm (0.039 in)
Input variable
M easured variable distance between process fitting and product sur-
face
3) W ith inductive load ohmic share min. 25 Ω/mH.
