59
11 Supplement
VEGABAR 83 • HART and accumulator pack
45035-EN-131107
Ʋ Cable entry ½ NPT
Ʋ Blind plug M20 x 1.5; ½ NPT
Ʋ Closing cap M20 x 1.5; ½ NPT
Plug options
Ʋ Signal circuit Plug M12 x 1, according to ISO 4400, Harting HAN,
7/8" FF
Ʋ Indication circuit M12 x 1 plug
Wire cross-section (spring-loaded terminals)
Ʋ Massive wire, cord 0.2 … 2.5 mm² (AWG 24 … 14)
Ʋ Stranded wire with end sleeve 0.2 … 1.5 mm² (AWG 24 … 16)
Display and adjustment module
Display element
Display with backlight
Measured value indication
Ʋ Number of digits 5
Ʋ Size of digits W x H = 7 x 13 mm
Adjustment elements 4 keys
Protection rating
Ʋ unassembled IP 20
Ʋ mounted into the housing without
cover
IP 40
Materials
Ʋ Housing ABS
Ʋ Inspection window Polyester foil
Integrated clock
Date format
Day.Month.Year
Time format 12 h/24 h
Time zone Ex factory CET
Rate deviation max. 10.5 min/year
Measurement electronics temerature
Resolution
1 °C (1.8 °F)
Accuracy ±1 °C (1.8 °F)
External battery charger
Mains voltage
100 … 240 V AC
Output voltage 24 V DC
Output current (shortcircuit proof) max. 500 mA
Load current limitation
70 mA
DC plug (inside plus, outside minus) 2.1 mm
