11 Supplement
VEGABAR 81 • HART and accumulator pack
45026-EN-131107
Isolating liquid p
abs
> 1 bar/14.5 psi p
abs
< 1 bar/14.5 psi Version for oxygen ap-
plications
High temperature oil
KN3.2 with cooling ele-
ment
-10 … +330 °C
(+14 … +626 °F)
+-10 … +200 °C
(+14 … +392 °F)
-10 … +60 °C
(+14 … +140 °F)
High temperature oil
KN3.2 with cooling ele-
ment 300 mm
-10 … +400 °C
(+14 … +752 °F)
+-10 … +200 °C
(+14 … +392 °F)
-10 … +60 °C
(+14 … +140 °F)
High temperature oil KN32
with capillaries 1 m, 2 m
or 5 m
-10 … +400 °C
(+14 … +752 °F)
+-10 … +200 °C
(+14 … +392 °F)
-10 … +60 °C
(+14 … +140 °F)
Halocarbon oil KN21 -40 … +150 °C (-
40 … +302 °F)
-40 … +80 °C (-
40 … +176 °F)
-
Halocarbon oil KN21 for
oxygen applications
-40 … +60 °C
(40 … +140 °F)
-40 … +60 °C
(40 … +140 °F)
-40 … +60 °C (-
40 … +140 °F)
Silicone-free liquid KN70 -40 … +70 °C (-
40 … +158 °F)
No vacuum -40 … +60 °C (-
40 … +140 °F)
Med. white oil KN92 (FDA) -10 … +150 °C
(+14 … +302 °F)
-10 … +160 °C
(+14 … +322 °F)
-10 … +60 °C
(+14 … +140 °F)
Med. white oil KN92 (FDA)
with cooling element
-10 … +250 °C
(+14 … +482 °F)
-10 … +160 °C
(+14 … +322 °F)
-10 … +60 °C
(+14 … +140 °F)
Med. white oil KN92 (FDA)
with cooling element
300 mm
- -10 … +160 °C
(+14 … +322 °F)
-10 … +60 °C
(+14 … +140 °F)
Mechanical stress, depending on the instrument version
Vibration resistance
1 to 4 g at 5 … 200 Hz according to EN 60068-2-6
(vibration with resonance)
Shock resistance 100 g, 6 ms according to EN 60068-2-27 (mechanical
shock)
Electromechanical data - version IP 66/IP 67 and IP 66/IP 68; 0.2 bar
Options of the cable entry
Ʋ Cable gland M20 x 1.5
Ʋ Cable diameter (options) 5 … 9 mm (0.20 … 0.35 in)
6 … 12 mm (0.24 … 0.47 in)
10 … 14 mm (0.39 … 0.55 in)
Ʋ Cable entry ½ NPT
Ʋ Blind plug M20 x 1.5; ½ NPT
Ʋ Closing cap M20 x 1.5; ½ NPT
Plug options
Ʋ Signal circuit Plug M12 x 1, according to ISO 4400, Harting HAN,
7/8" FF
Ʋ Indication circuit M12 x 1 plug
Wire cross-section (spring-loaded terminals)
Ʋ Massive wire, cord 0.2 … 2.5 mm² (AWG 24 … 14)
