3 Supplement
Centering • for VEGAFLEX series 80
44967-EN-131119
Product temperature -196 … +450 °C (-321 … +842 °F)
Weight
Ʋ Centering weights with height 30 mm
(1.17 in)
approx. 280 … 1540 g (10 … 54 oz)
Ʋ Centering weights with height 90 mm
(3.54 in)
approx. 410 … 600 g (14.5 … 21.2 oz)
Gravity weight (S1, S2)
Material
Ʋ Gravity weight 316L
Ʋ Threaded pins 316L
Diameter
Ʋ Gravity weight ø 20 mm (0.79 in)
Ʋ with plastic spacer ø 95 mm (3.74 in), notches ø 75 mm and ø 48 mm (3 in
and 1.9 in)
Length 50 mm/100 mm (1.97 in/3.94 in)
Product temperature -196 … +450 °C (-321 … +842 °F) 5)
Weight approx. 100 … 200 g (3.5 … 7 oz)
5) with plastic spacer only up to +250 °C (+482 °F)
