Seal between housing and housing
cover
NBR (stainless steel housing), silicone (Alu/plastic
housing)
-
Ground terminal
316L
Sensor length
See chapter "Dimensions"
Weight
-
Instrument weight (depending on proc-
ess fitting)
0.8 … 4 kg (0.18 … 8.82 lbs)
-
Weight - External housing
0.7 … 1.5 kg (1.543 … 3.307 lbs), depending on
housing material
Process fittings
-
Pipe thread, cylindrical (ISO 228 T1)
G
1½ A
-
American pipe thread, tapered
1½ NPT
-
Flanges
DIN from DN 50, ANSI from 2"
-
Mounting adapter
G
2 A or 2 NPT
Frequency range
K band, 24.085 GHz (ISM band)
Measuring range
0.1 … 100 m (0.33 … 328 ft)
Beam angle
1)
-
Threaded version - internal horn antenna
(PTFE cover)
20 °
-
Plastic encapsulated antenna with PP
cover
10 °
-
Horn antenna (316L) - ø 40 mm (1.575 in)
22 °
-
Horn antenna (316L) - ø 48 mm (1.89 in)
18 °
-
Encapsulated antenna with PTFE cover -
Flange DN 50, ANSI 2"
18 °
-
Encapsulated antenna with PTFE cover -
Flange DN 80 … DN 150, ANSI 3" … 6"
10 °
Output variable
Output
Relay output (DPDT), 2 floating spdts
Switching voltage max.
253 V AC, 253 V DC
Switching current max.
5 A AC, 1 A DC
Breaking capacity
-
Min.
50 mW
-
Max.
750 VA AC (cos phi > 0.5), 40 W DC (ohmic load)
If inductive loads or stronger currents are switched
through, the gold plating on the relay contact
surface will be permanently damaged. The contact
is then no longer suitable for switching low-level
signal circuits.
1)
Outside the specified beam angle, the energy of the radar signal has a level
of -3 dB (50 %)
