11 Supplement
VEGAPULS 68 • Modbus and Levelmaster protocol
41370-EN-121011
Register Name Register Number Type Note
QV 1438 Quarternary Variable in Byte Order CDAB
Status 2000 DWord See Register 100
PV 2002 DWord Primary Variable in Byte Order ABCD (Big Endian)
SV 2004 DWord Secondary Variable in Byte Order ABCD (Big Endian)
TV 2006 DWord Third Variable in Byte Order ABCD (Big Endian)
QV 2008 DWord Quarternary Variable in Byte Order ABCD (Big En-
dian)
Status 2100 DWord See Register 100
PV 2102 DWord Primary Variable in Byte-Reihenfolge DCBA (Little En-
dian)
SV 2104 DWord Secondary Variable in Byte-Reihenfolge DCBA (Lit-
tle Endian)
TV 2106 DWord Third Variable in Byte-Reihenfolge ABCD DCBA (Lit-
tle Endian)
QV 2108 DWord Quarternary Variable in Byte-Reihenfolge DCBA (Lit-
tle Endian)
Status 2200 DWord See Register 100
PV 2202 DWord Primary Variable in Byte Order BACD (Middle Endian)
SV 2204 DWord Secondary Variable in Byte Order BACD (Middle En-
dian)
TV 2206 DWord Third Variable in Byte Order BACD (Middle Endian)
QV 2208 DWord Quarternary Variable in Byte Order BACD (Middle En-
dian)
Unit Codes for Register 104, 108, 112, 116
Unit Code Measurement Unit
32 Degree Celsius
33 Degree Fahrenheit
40 US Gallon
41 Liters
42 Imperial Gallons
43 Cubic Meters
44 Feet
45 Meters
46 Barrels
47 Inches
48 Centimeters
49 Millimeters
