7 Set up with the display and adjustment module
FIBERTRAC 31 • 4 … 20 mA/HART - four-wire
43386-EN-131119
Menu Menu item Default value
Setup Measurement loop name Sensor
Isotope Cs-137
Application Level
Adjustment 0 %, 100 %
Linearization 0 ct/s ≙ 100 %
90000 ct/s ≙ 0 %
Background radiation 0 ct/s
Unit of the process value %
Temperature unit °C
Damping 60 s (manually)
Real value correction 0
Current output Activated
Current output mode 4 … 20 mA, < 3.6 mA
Current output Min./Max. Min. current 3.8 mA, max. current 20.5 mA
Reference value - Relay None
Mode Overfill protection
Upper switching point -
Process value
0 %
Lower switching point -
Process value
0 %
Upper switching point -
Temperature
50 °C
Upper switching point -
Temperature
25 °C
Block adjustment Released
Address - Summation
Slave
free
Display Language Selected language
Displayed value Pulse rate
Display unit ct/s
Additional adjustments Temperature unit °C
Linearisation curve Empty
HART mode Standard
Address 0
With this function you can select the mode.
The sensor offers the HART modes standard and multidrop.
The mode 'Standard' with the fixed address 0 (factory setting) means
output of the measured value as 4 … 20 mA signal.
This parameter is described in the operating instructions manual
"Display and adjustment module".
Additional adjustments/
HART mode
