6 Setup
VEGASOURCE 35 •
38132-EN-130415
•
Secure the switch position ON with the padlock (1) in the specified
position
•
Tighten locking screw (2)
Radiation ON
The label EIN - ON is visible. The marking arrow points to EIN - ON.
Radiation OFF
The label AUS - OFF is visible. The marking arrow points to AUS -
OFF.
Switching off the radiation is carried out analogously to this proce-
dure. To switch off the radiation, turn the stirrup (3) 180° clockwise.
6.5 Operation VEGASOURCE 35 - version K L M N
(pneumatic switching facility)
Warning:
Make sure before switching on the radiation that no persons are
inside the radiation areas (also not inside the vessel).
Radiation must only be switched on by trained personnel.
Note:
The pneumatic actuator must not be used under ambient conditions
that can cause corrosion in and on the pneumatic actuator.
For use in hazardous areas of category ATEX II 2 G, the correspond-
ing safety instructions must be noted.
The figures in brackets refer to the following illustration.
Indication of the switch-
ing status
Switching the radiation
off
Switching the radiation
on
