32
10 Supplement
PLICSMOBILE T61 • External GSM/GPRS radio unit
37700-EN-130228
10 Supplement
10.1 Technical data
General data
316L corresponds to 1.4404 or 1.4435, 316Ti corresponds to 1.4571
Materials
Ʋ Housing plastic PBT, Alu die-casting, 316L
Ʋ Ground terminal 316Ti/316L
Weight
Ʋ Plastic housing 595 g (1.311 lbs); 633 g (1.396 lbs) with external an-
tenna
Ʋ Aluminium housing 1231 g (6.415 lbs)
Voltage supply
Operating voltage
1) 8 … 32 V DC
Power consumption 2)
Ʋ Power saving mode (9 V/12 V) 0.18 mW/0.3 mW
Ʋ Power saving mode (24 V/32 V) 1.8 mW/3.7 mW
Ʋ Permanent operation 1.1 W
Ʋ Peak power (measured value trans-
mission)
5.1 W
Power requirement 3)
Ʋ Measurement cycle incl. transmission 20 mWh
Battery pack (optional)
Battery type
Lithium (not chargeable)
VEGA order code PM-BATT.
Operating voltage 18 V DC
Capacitance approx. 3.5 Ah
Accumulator pack with charging electronics (optional)
Accumulator type
6x NiMH series AA (Mignon)
Manufacturer/series Panasonic/Evolta
VEGA order code PM-AKKUAA
Capacitance 2050 mAh
Nominal voltage accumulator pack 7.2 V DC
Charging voltage accumulator pack 20… 32 V DC
Ambient temperature
Ʋ Charging 0 … +55 °C (32 … +131 °F)
1) When the instrument is powered by an external voltage supply, make sure the voltage supply unit has a suf-
ficient current carrying capacity. With a voltage supply <9.6 V, current peaks of up to 2 A must be expected.
2) The listed power specifications include the voltage supply of a HART sensor with 20 mA
3) The listed energy requirement includes the voltage supply of a HART sensor (VEGAPULS 61 with 4 mA (multi-
drop mode) and 12 V operating voltage
