Indication
Signal lamp (LED)
-
Green Switching output closed
-
Red Switching output open
-
Red (flashing) Failure (switching output open)
Output variable
Transistor output
Load current
max. 250 mA
Voltage loss max. 3 V
Turn-on voltage max. 34 V DC
Blocking current
< 10 µA
Contactless electronic switch
Load current
min. 10 mA/max. 250 mA
Domestic current requirement approx. 4.2 mA
Mode
-
Min./Max. Changeover by electronic connection
-
Max. Overflow protection
-
Min. Dry run protection
Voltage supply
Transistor output
Operating voltage
9.6 … 35 V DC
Power consumption max. 0.5 W
Contactless electronic switch
Operating voltage
20 … 253 V AC/DC
Power consumption max. 0.5 W
Electromechanical data
Valve plug ISO 4400
-
Wire cross-section 1.5 mm²
-
Outer cable diameter 4.5 … 7 mm
Electrical protective measures
Protection rating
-
Valve plug ISO 4400 IP 65
-
M12 x 1 plug connection IP 66/IP 67
Overvoltage category III
Protection class - Transistor output II
Protection class - Contactless electronic switch I
VEGASWING S 51 21
