10 Supplement
PLICSRADIO R61 • Wireless receiving unit (single channel)
32625-EN-130228
10 Supplement
10.1 Technical data
General data
316L corresponds to 1.4404 or 1.4435, 316Ti corresponds to 1.4571
Materials
Ʋ Housing plastic PBT, Alu die-casting, 316L
Ʋ Inspection window in housing cover
for display and adjustment module
Polycarbonate (UL-746-C listed)
Ʋ Ground terminal 316Ti/316L
Weight
Ʋ Plastic housing 840 g (1.851 lbs)
Ʋ Aluminium housing 1300 g (2.866 lbs)
Voltage supply
Operating voltage depending on the version of the power supply unit
Ʋ 24 V version 9.6 … 48 V DC, 24 … 42 V AC
Ʋ 115/230 V version 90 … 253 V AC, 50/60 Hz
Max. power consumption depending on the type of power supply unit
Ʋ 24 V version 5.2 VA; 3.1 W
Ʋ 115/230 V version 4 VA; 1.8 W
Current output
Quantity
1 x output
Function Current output for measurement loop 1
Range 4 … 20 mA
Resolution 1 µA
Max. load 500 Ω
Fault message 0; 3.6; 4; 20; 20.5; 22 mA (changeable)
Linearity error 0.12 % (relating to 20 mA)
Temperature error 0.002 %/10 K (relating to 20 mA)
Radio transmission
Radio frequency
Ʋ Standard version 2450.15 … 2459.75 MHz
Ʋ Version increased range 2) 920 … 927.2 MHz
Antenna connection R-SMA
Antenna type, standard Isotropic (Omni) antenna
Emitted power, standard antenna
Ʋ Standard version 15 dBm (32 mW)
Ʋ Version increased range 19 dBm (80 mW)
Antenna gain, standard antenna
2) Only permitted in USA/Canada
