Ambient conditions
Ambient, storage and transport temperature -40 … +80 °C (-40 … +176 °F)
Process conditions
Process pressure
-
Version A with PP flange 0 kPa
-
Other versions -20 … 50 kPa/-0.2 … 0.5 bar (-2.9 … 7.3 psi)
Process temperature (transducer temper-
ature) -40 … +80 °C (-40 … +176 °F)
Vibration resistance mechanical vibration with 1 g in the frequency
range 5 … 200 Hz
9)
Electromechanical data
Cable entry
-
Double chamber housing l
1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5; plug M12 x 1 for
VEGADIS
61 (optional)
or:
l
1 x closing cap ½ NPT, 1 x blind stopper
½ NPT
, plug M12 x 1 for VEGADIS 61
(optional)
or:
l
1 x plug (depending on the version), 1 x blind
stopper M20 x 1.5; plug M12 x 1 for VEGADIS
61 (optional)
Spring-loaded terminals for wire cross-sec-
tion up to 2.5 mm² (AWG 14)
Transducer cable 10)
-
Length 5 … 300 m (16.4 … 984.3 ft)
-
Diameter 7.2 … 7.6 mm (0.283 … 0.299 in)
Indicating and adjustment module
Voltage supply and data transmission through the sensor
Indication LC display in dot matrix
Adjustment elements 4 keys
Protection
-
unassembled IP 20
-
mounted into the sensor without cover IP 40
9) Tested according to the regulations of German Lloyd, GL directive 1.
10) With separate version C and D.
