10 Supplement
10 .1 Technical data
General data
316L corresponds to 1.4404 or 1.4435, 304 corresponds to 1.4301
Materials, wetted parts with encapsulated antenna system
-
Threaded fitting G1½ A and 1½ NPT PVDF
-
Hygienic fitting Adapter of 316L
-
Antenna PVDF
-
Seal thread FKM (Viton)
-
Seal, bolting FKM (Viton)
Materials, wetted parts with plastic horn antenna
-
Horn antenna PBT-GF30
-
Focussing lens PP
-
Adapter flange PPH
-
Seal, adapter flange FKM (Viton)
Materials, non-wetted parts
-
Compression flange PPH
-
Mounting strap 316L
-
Fixing screws, mounting strap 316L
-
Fixing screws, adapter flange 304
-
Housing Plastic PBT (polyester), Alu die-casting powder-
coated, 316L
-
Seal between housing and housing
cover NBR (stainless steel housing), silicone (Alu/plastic
housing)
-
Inspection window in housing cover for
PLICSCOM Polycarbonate (UL-746-C listed)
-
Ground terminal 316Ti/316L
Max. torque, mounting screws - strap on the
sensor housing 4 Nm
Weight depending on process fitting and
housing material 0.7 … 3.4 kg (1.543 … 7.496 lbs)
Output variable
Output
-
Signal digital output signal, Foundation Fieldbus protocol
-
Physical layer according to IEC 61158-2
Cycle time min. 1 s (dependent on the parameter setting)
-
Damping (63 % of the input variable) 0 … 999 s, adjustable
-
Fulfilled NAMUR recommendations NE 43
Channel Numbers
