Page 43
Installation
39
Installation
Telephone base installation
The telephone can be adapted to desktop use or mount on a standard telephone wall plate.
Installation option - desktop position
Turn the telephone base over with the bottom side facing up. Route the small end of the power adapter cord out from the top
eyelet on the mounting bracket. Then connect it into the power jack at the bottom of the telephone base.
1.
Power jack
Screw
SIP contemporary trimstyle 1-line/2-line - S2310-6VDC/S2320-6VDC
Insert the tabs into the upper grooves and tighten the screw to affix the mounting bracket.
2.
Plug the large end of the power adapter into the electrical outlet not controlled by a wall switch. Then connect the coiled handset
cord to the telephone base.
3.
