6 VMBDMI Dimmer manual – edition 1
OVERVIEW
Connections LED indications
1 mains voltage 5 Power supply
2 Load 6 Receiving Velbus data
3 Velbus power supply 7 Sending Velbus data
4 Velbus 8 Output status
3 4
6
5 7
8
2 1
