12 VMBDMI Dimmer manual – edition 1
Configuration
This dimmer module can only be configured using the VelbusLink software.
The address, dimmer mode and control functions can be configured.
Address:
Every module in the Velbus system must have a unique address.
Address setting is done by software.
Dimmer mode:
The dimmer defaults to inductive loads. It will switch off when the load is to inductive. When using dimmable LED
lamps it is recommended to disable this protection by setting the dimmer mode to resistive loads.
Control functions:
The dimmer module is controlled via pushbuttons connected to the Velbus system using a pushbutton interface or
control panel.
Up to 37 different pushbuttons can be assigned. Every pushbutton can activate a different function.
Function Description
1 Momentary Light remains on as long as switch is closed
2 Off Light is switched off. To create an ‘all off’ function, on every dimmer the
same pushbutton is assigned the ‘off’ function.
3 Off with timer lock The light is switched off; the timers can not be started.
4 Off with timer lock after short
push A short push on the pushbutton switches off the light; the timers can
not be started. A long push will switch off the lights; all timer functions
remain available.
5 Off with timer lock after long
push A short push on the pushbutton switches off the light; all timer functions
remain available. A long push will switch off the lights; the timers can
not be started.
6 Slowly off The light slowly dims during the specified time duration.
7 On The light is switched on.
8 On with timer lock The light is switched on; the timers can not be started.
9 On with timer lock after short
push A short push on the pushbutton switches on the light; the timers can
not be started. A long push will switch on the lights; all timer functions
remain available.
10 On with timer lock after long
push A short push on the pushbutton switches on the light; all timer functions
remain available . A long push will switch on the lights; the timers can
not be started.
11 Slowly on The light slowly turns brighter during the specified time.
12 On/off Every push reverses the condition of the light.
13 On/off with timer lock Every push reverses the condition of the light (on/off).
When the light is on, timers can not be started.
14 On/off with timer lock after
short push Every push reverses the condition of the light. Only when the light was
switched on via a short push the timers can not be started.
15 On/off with timer lock after long
push Every push reverses the condition of the light. Only when the light was
switched on via a long push the timers can not be started.
16 Slowly on/off Every push will slowly switch the light on or off during the specified
time durations.
17 Start/stop timer A push will switch on the light during a specified time.
Another push while the light is on switches the light off immediately.
