May 2007
1s - 60 hour start-stop timer module VM141
START-button
STOP-button
Timing indicator leds
Range select:
1.. 6s
1.. 60s
1.. 60 min
1.. 60 hours
Relay output
3A max.
COM
NC
NO
Time adjust
12VDC/100mA
Features & specifications:
•
Wide timing range
•
Easy time setting
•
Led animation during operation
•
On-board START-STOP buttons
•
Non retriggerable
•
Power-on trigger is possible
•
Debounced buffered inputs avoid
false triggering
•
Compact size
•
Front panel mountable
•
Adjustable delay: 1s - 60h
•
Power supply: 12VDC / 100mA
•
NO/NC relay: 24VAC/DC 3A max.
•
Dimensions: 70x45x20mm
Buffered remote
pushbutton
inputs
