VM119 One channel dual output receiver
(for use with our VM118R transmitter)
November 2007
• For use with VM118R (or K8058 kit) RF
transmitters.
• Relay contacts NO / NC: 3A max. each.
• 433MHz operation.
• Selectable timers per output: 0.5s, 5s, 30s, 1min,
5min, 15min, 30min and 60min
• Open field range of up to 30m possible.
• Power supply : 9 to 12V AC or DC / 100mA max.
• Dimensions : 80x70x25mm.
Specifications:
More features:
•
Easy setup and transmitter ‘learning’, no
jumper settings
•
Toggle or pulse function selectable per output
•
Pulse function can have turn off timer
•
Up to 31 different VM118R transmitters or
transmitter buttons can be stored
•
‘All clear’-function
•
LED indicators for outputs and functions
All clear
VM118R
8-Ch RF transmitter
Unique
Feature:
Dual output
A single transmitter key-press activates two
independent outputs.
Each output can be configured as toggle, pulse or
pulse with timer.
This allows you to e.g. Start two different timers,
have a pulsed and a timed output, have two
galvanically separated outputs, etc
Easy fixation
Using multiple receivers of this type in combination with our 8 channel transmitter, will allow
you to control remotely up to 8 devices at different places.
e.g. Perfectly suited for hide –away control situations, for demonstrations, home use...
LED status indicators
