November 2008
BRAKE LIGHT FLASHER MK178
Technical:
Power supply: 12-15VDC
Max load: 4A
Flash frequency: 7 times per second
Selectable number of flashes: 5 or 10 times.
Selectable flash repeat interval: always or not within 5-7sec between two brakes
Dimensions: approx 60x30x20mm
>>> INCREASES SAFETY <<<
Works on every car with a third brake light, with either LEDs or incandescent bulbs
EASY TWO-STEP INSTALL
CUT
WIRE
INSERT
KIT
60mm
30mm
Regular brake light
With MK178 flashing brakelight
REACTION TIME:
WARNING: Check with local authorities if
the use of this device is allowed in your
country
Makes your 3rd brake light flash 5 or 10 times (selectable) before brake light is turned-on in a
steady fashion
Brake light does not flash when brake pedal is pressed within 5s after first press (selectable).
* package includes shrink tube
to cover complete unit.
