Velleman projects VM156 Datasheet - Manual

August 2008
Specifications:
SINE
BURST
NOISE
Level Adj.
Freq / Mode select
button at the back
Freq / Mode
indicators
Great l
ittle too
l
for ser
vice, re
pair,
testing
, educt
ion,
etc...
Pocket Audio Generator VM156
New
Pro
duc
t inf
o
Microprocessor technology
Digital waveform generation
Sine wave : 50Hz, 100Hz, 1KHz, 10KHz, 20KHz
Burst : 50Hz, 100Hz, 1KHz
Burst mode : 20ms ON, 500ms OFF
Noise : 32-bit digital noise
Output level (10Kohm): 0 to 775mV (0dB)
Outputs : 2 x RCA (cinch)
Power supply : 2 x CR2016 or CR2025 battery (excl.)
Dimensions : 86 x 50 x 25 mm
