Velleman К8048 User Manual
Page 14
PIC programmer board
12
Step-by-step execution of a sample program.
For our example we will use the program demo1.asm, a simple running light:
·
Verify whether the adapter and the serial connection of your K8048/VM111 are connected and
make sure the programmer software has been installed on your PC.
·
Compile the file 'demo1.asm' with MPASM.EXE (see Compiling)
·
Start the programmer software, PICPROG2.EXE
·
Check all settings (PIC16F627), the serial port and the communication speed always start with
the 'LOW' setting).
·
Read in the compiled file, demo1.hex. (File...open file...)
·
Put SW5 in the 'PROG' position.
·
Click on 'WRITE' in the PICPROG2 software.
·
Now you can monitor the writing process on the activity screen.
·
Put SW5 in the 'RUN' position when the programming is completed. LEDs LD1 to LD6 should
now form a running light.
