Velbus manual VMB1BL – edition 1 – rev.2.0
6
Control through the VELBUS system:
L H UP DWN
BUS
VMB1BL
L
H
12V SUPPLY
BUS
TWISTED
PAIR (0.5mm )
2
+
12V
-
COM L DOWN UP
+
-
N
L
AC POWER
OUT
TIME
ADDR
PB
M
UP
DOWN
Combination of direct push button and VELBUS control:
L H UP DWN
BUS
VMB1BL
UP PUSH BUTTONS
L
H
12V SUPPLY
BUS
TWISTED
PAIR (0.5mm )
2
+
12V
-
COM L DOWN UP
+
-
N
L
AC POWER
OUT
TIME
ADDR
PB
M UP
DOWN
DOWN PUSH BUTTONS
Remark:
Connect the bus (mind the polarity) to the module. Use a twisted pair cable with a 0.5mm
2 gauge or more with
very long connections.
