7
Assembly
 Connect the battery terminal to the point marked “+” (red) and “-” (black), see figure 2.0.
 Connect the windings to their respective points marked with a, b, (L1) and c, d (L2), see figure 3.0.
10. Assembly
Fig. 2.0
Red
Black
Fig. 3.0
MAKE SURE TO
SCRAPE OFF THE
LACQUER!
